Design & Manufacturer ASME B 16.34 / BS EN ISO 17292 Valve Face To Face Dimension As Per Manufacturer Standard Inspection And Testing API 598/ ISO - 5208/ BS EN 12266 - 1 Size Range 1/2“ To 12” Flanged Media Air/ Water/ Oil & Gas Body Material CAST IRON(CI), DUCTILE IRON(DI), S.G IRON(SGI), WCB, CF8, CF8M, CF3M , SS 304L , DUPLEX , HAST ALLOY, MONEL CF8, CF8M Seat Material PTFE, RPTFE, CFT, GFT, MODIFIED PTFE, AIRA-250, NYLON, DEVLON, PEEK Flange Drilling Asme B 16.5 Class 300#/ Din/ Jis Leakage Class ISO 5208 Class VI / FCI - 70- 2/ ASME, ANSI B 16,16.104“ End Connection ISO 7-1 FOR BSPT / ASME B 1.201 FOR NPT FOR S/E Temperature Range PTFE : Upto 180°C / PEEK : 250°C RPTFE : Upto 220°C / AIRA250” Pressure Class 300# Ball Material CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M Ball Type Hollow, Solid Stem Material Aisi 410, Ss 304, Ss 316, Ss 304l, Ss 316l, Duplex 2205, Duplex 2507, Monel Features & Benefits High Cycle Life Antistatic Design & Fire Safe Design As Per API 607 Blow Outproof Stem Locking Handle Available ISO 5211 Mounting Pad Available V-type Cheuron Gland Packing Which Leads To Zero Leak After Thousands of cycle
