Design & Manufacturer ASME B16.34/ BS EN ISO 17292 Valve Face To Face Dimension ASME B16.10 Inspection & Testing API 598/ ISO-5208/ BS EN 12266-1 Size Range 1/4“ To 4” Tempreature Range PTFE : Upto 180°C/ PEEK : 250°/ RPTFE : Upto 220°C/ AIRA250°C Ball Material CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M Ball Type Hollow & Solid Certification Design CE Approved, SIL3 Approved, IBR Approved, POD Approved & Fire Safe Approved Leakage Class ISO 5208 Class VI/ ASME B16.104, ANSI FCI 70-2( BUBBLE TIGHT SHUTOFF) End Connection ISO 7-1 FOR BSPT/ ASME B1.20.1 FOR NPT FOR SCREWED Pressurre Class 150# Media Air / Water / Oil & Gas Etc... Body Material CF8, CF8M, CF3M, SS 304L, WCB, DUCTILE IRON(DI), DUPLEX, HAST ALLOY, MONEL Stem Material AISI 410, AISI 304, AISI 316, AISI 304L, AISI 316L, DUPLEX 2205, DUPLEX 2507, MONEL Seat Material PTFE, RPTFE, CFT, GFT, MODIFIED PTFE, AIRA-250, NYLON, DEVLON, PEEK Features & Benefits 1- High Cycle Life. 2- Antistatic Design & Fire Safe Design As Per API 607. 3- Blow Outproof Stem. 4- Locking Handle Available. 5- ISO 5211 Mounting Pad Available. 6- V-type Cheuron Gland Packing, Which Leads To Zero Leak After Thousand Of Cycle. 7 – Best For Cryogenic Application.
