Design & Manufacturer ASME B16.34/ BS EN ISO 17292 Valve Face To Face Dimension ASME B16.10/ BS EN ISO 17292 Inspection & Testing API 598/ ISO-5208/ BS EN 12266-1 Leakage Class ISO 5208 Class VI / FCI - 70 - 2/ ASME 16.104/ BUBBLE TIGHT SHUTOFF End Connection ASME B16.5 CLASS 150 Size Range 3/4“ To 14” Flanged Tempreature Range PTFE : Upto 180°C / PEEK : 250° , RPTFE / TFM -220°C Pressurre Class 150# Media Air/ Water/ Oil & Gas Body Material WCB, CF8, CF8M, CF3M, SS 304L, DUPLEX, HAST ALLOY, MONEL. Ball Material CF8, CF8M, WCB + ENP, HAST ALLOY, DUPLEX, MONEL, CF3M Ball Type Hollow & Solid Stem Material AISI 410, AISI 304, AISI 316, AISI 304L, AISI 316L, DUPLEX 2205, DUPLEX 2507, MONEL Seat Material PTFE, RPTFE, CFT, GFT, MODIFIED PTFE, AIRA-250, NYLON, DEVLON, PEEK Flange Drilling ASME B16.5 Class 150#/ Din/ Jis Certification Design CE Approved, SIL3 Approved, IBR Approved, POD Approved, EIL Approved &, Fire Safe Approved 1 – High Cycle Life. 2 – Antistatic Design. 3 – Locking Handle Available. 4 – ISO 5211 Mounting Pad Available. 5 – V-type Cheuron Gland Packing, Which Leads To Zero Leak After Thousands Of Cycle.
