Size Range 15MM To 100MM Tempreature Range PTFE 180°C / CFT 220°C Pressurre Class Upto 10 BAR Shutoff Rating Tight Shut off Body Style Y - Body - Screw End, Flange End, Triclover End Flange Drilling 150# Certification CE Approved Body Materials S. S - 304, S. S - 316-L Stem Materials S. S - 304 Seat Materials PTFE, CFT, GFT Plug Materials S. S - 304 Design Standard Manufacture - Standard Testing Standard API - S98, PN10 Face To Face Manufacture - Standard Leakage As Per ANSI B16, 16.104 Leakage Class VI Shut Off Tight / Bubble Tight Applications Air / Water / Oil / Gas / Steam & Chemical Features & Benefits 1 – “Y” Type Construction For On / Off Application Having Self – Cleaning Features. 2 – Best Choice For Speedy And Multiple Operation. 3 – Due To Angle Shape, Easy To Mount At Congested Place. 4 – Due To Angle Seated Body, Insensitive To The Contaminated Fluids. 5 – Full Flow With Negligible Pressure Drop.
