5/3 Way 3 Position Double Pilot Valve

Model 3ADDP-5

Size 1/4”, 1/2”

Body Aluminium Anodized

Valve Type PAN | PHN | PRN

Seals Nitrile

Pressure 1 to 10 Kg/Cm²

Temperature 5 to 55°C

Leakage Bubble Tight

Media Compressed Air (Filtered & Lubricated)

Description

This 5/3 way 3 position double pilot valve is designed to control the flow of compressed air in a pneumatic system. It utilizes a spool type design, featuring a sliding spool to regulate airflow. The valve comes in two sizes: 1/4″ and 1/2″. It can withstand a pressure range of 1 to 10 Kg/cm² and temperatures between 5 to 55 ˚C. Notably, the valve is bubble tight, signifying an exceptionally low leakage rate.

In addition to manufacturing these valves, we at Airmax Pneumatics are proud to supply and export them across India and worldwide. If you’re looking for a step up from our basic model, consider this RM series 5/3 way 3 position double pilot valve medium-range option with added features.
